| Modnum |
42230 |
| Series |
Speeder |
| Frame |
SPEEDER LITE II, material: aluminum, 700x35C max. wheelsize, 100x9/135x9mm axle standard, BSA bottom bracket standard |
| Color |
SILK CHAMPAGNE (BLACK) (bw) |
| Fork |
MERIDA SPEEDER CF2, Tapered, material: carbon , 700x35C max. wheelsize |
| Front derailleur |
Shimano TY710 |
| Rear derailleur |
Shimano Acera-X |
| Front gear shifter |
Shimano ST-EF505 |
| Rear gear shifter |
Shimano ST-EF505 |
| Brake levers |
Shimano EF505 |
| Front brake |
Shimano ST-EF505, BR-MT200 brake caliper/ 160 mm |
| Rear brake |
Shimano ST-EF505, BR-MT200 brake caliper/ 160 mm |
| Chain |
Sunrace CN-M84 |
| Crankset |
Shimano TY301, 48-38-28 teeth, 170 mm-all sizes |
| Cassette |
Sunrace CSM558, 11-32 teeth, 8 speed |
| Bottom bracket |
FSA TH-7420ST Cartridge Bearing |
| Seatpost |
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 12mm setback |
| Saddle |
MERIDA COMP SL, V-mount |
| Front hub |
Joytech D471SBT-SC-CL, 100x9mm width front hub, 28 spoke holes, centerlock |
| Rear hub |
Shimano FH-TX505, 135x9mm width rear hub, 32 spoke holes, centerlock |
| Tires |
Maxxis Detonator, 700x32C, wire // Maxxis Detonator, 700x32C, wire |
| Rims |
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium |
| Wheels |
700 |
| Handlebar |
MERIDA COMP TK, material: aluminium, 600mm width, Flat |
| Stem |
MERIDA COMP CC, material: aluminium, 31.8mm diameter, 6° stem angle, 80 mm-XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL |
| Headset |
MERIDA M2341 Neck |
