| Series |
Crossway |
| Year |
2022 |
| Frame |
CROSSWAY TFS III, material: aluminum, 700x50C max. wheel size, 135x9mm axle standard, BSA bottom bracket standard |
| Color |
SILK CHAMPAGNE (BLUE) |
| Fork |
Suntour NEX HLO, Coil, 63mm suspension travel, lockout, 700x50C max. wheelsize |
| Front derailleur |
Shimano FD-M370 |
| Rear derailleur |
Shimano RD-M370 |
| Front gear shifter |
Shimano ST-EF505 |
| Rear gear shifter |
Shimano ST-EF505 |
| Front brake |
Shimano ST-EF505, BR-MT200 brake caliper/ 160 mm |
| Rear brake |
Shimano ST-EF505, BR-MT200 brake caliper/ 160 mm |
| Chain |
KMC M99 |
| Cassette |
Shimano CS-HG200, 11-32 teeth, 9 speed |
| Bottom bracket |
FSA TH-7420ST-W, Cartridge Bearing |
| Seatpost |
MERIDA TK, 27.2mm diameter, 13mm setback, 40mm seatpost suspension travel |
| Saddle |
MERIDA Cross Sport |
| Front hub |
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock |
| Rear hub |
Shimano TX505, 135x9mm width rear hub, 32 spoke holes, Centerlock |
| Tires |
MERIDA K1171, 700x40C, wire // MERIDA K1171, 700x40C, wire |
| Rims |
MERIDA CC, 17mm inner width, material: aluminium |
| Wheels |
700 |
| Handlebar |
MERIDA CC, material: aluminium, 660mm width, 25mm rise |
| Stem |
MERIDA TK, material: aluminium, 25.4mm diameter, adjustable, 100 mm all sizes |
| Headset |
FSA TH888/NO.10 |
