| Modnum |
42909 |
| Series |
eOne-Sixty |
| Frame |
eONE-SIXTY LITE III, material: aluminium, 150mm suspension travel, 27.5x2.8 max. wheelsize, 148x12mm axle standard, intube |
| Color |
RED/BLACK |
| Fork |
Marzocchi Z1 Ebike+, Air, 160mm suspension travel, Tapered, 51mm fork offset, 29x2.6 max wheelsize |
| Shock |
FOX Float DPX2 Performance, platform |
| Motor |
Shimano EP8 |
| Display |
Shimano SC-E7000 |
| Battery |
Simplo Internal Battery, 750Wh |
| Rear derailleur |
Shimano XT RDM8100 Shadow+ 12 |
| Front gear shifter |
Shimano SL -MT500-IL |
| Rear gear shifter |
Shimano DEORE M6100 12 |
| Front brake |
Shimano SLX, 4 piston/ 203 mm |
| Rear brake |
Shimano SLX, 4 piston/ 203 mm |
| Chain |
KMC e12T EPT |
| Cassette |
Shimano M6100, 10-51 teeth, 12 speed |
| Bottom bracket |
included |
| Seatpost |
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, XS: 100mm travel seatpost - S/M 150mm travel seatpost - L/XL 170mm travel seatpost |
| Saddle |
MERIDA EXPERT CC, V-mount, incl. MERIDA minitool |
| Front hub |
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock |
| Rear hub |
Shimano SLX, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Maxxis Assegai, 29x2.5 , fold, TR EXO+ 3C MaxxGrip // Maxxis DHR II, 27.5x2.6 , fold, 3C EXO+ TR |
| Rims |
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
| Wheels |
29 |
| Handlebar |
MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Stem |
MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0° stem angle, GoPro & Supernova mount, 40 mm all sizes |
| Headset |
MERIDA-8152 |
