| series |
Flint |
| Year |
2022 |
| Frame |
SILEX LITE, material: aluminium, 700x38C / 650Bx45C max.WHS, 100x12/142x12mm axle standard, BB86 bottom bracket standard |
| Color |
MATT RACE RED |
| Fork |
MERIDA SILEX CF2, Tapered, material: carbon, 700x38C / 650Bx45C max. wheelsize |
| Front derailleur |
Shimano GRX810 |
| Rear derailleur |
Shimano GRX810 |
| Forward speed control |
Shimano GRX810 |
| Reverse speed control |
Shimano GRX810 |
| Brake leverage |
Shimano GRX810 |
| Front brake |
Shimano GRX810, Hydraulic disc/ 160mm |
| Rear brake |
Shimano GRX810, Hydraulic disc/ 160mm |
| Channel |
KMC X11 |
| Cassette |
Shimano CS-HG700, 11-34 teeth, 11 speed |
| Pedal axle |
Shimano Pressfit BB71 |
| Seat post |
MERIDA EXPERT CC, material: carbon, 30.9mm diameter, 0mm setback |
| Saddle |
MERIDA COMP SL, V-mount, incl. MERIDA minitool |
| Front hub |
VP CLK170F, 100x12mm width front hub, 32 spoke holes, centerlock |
| Rear hub |
VP CLK270R, 142x12mm width rear hub, 32 spoke holes, centerlock |
| Tires |
Maxxis Rambler, 700x38C, fold, TR, EXO // Maxxis Rambler, 700x38C, fold, TR, EXO |
| Rims |
MERIDA EXPERT CX, 19mm inner width, 24mm height, material: aluminium |
| Wheels |
700 |
| Hanger |
MERIDA EXPERT GR, material: aluminium, 400mm (XS-S), 420mm (M), 440mm (L/XL) |
| Stem |
MERIDA EXPERT CW, material: aluminium, 31.8mm diameter, -8° stem angle, 80 mm all sizes |
| Management |
MERIDA M2331 |
