The 15–80 V to 12 V waterproof DC-DC converter is designed to safely power your electrical accessories from the main battery of your bike, scooter, or electric vehicle. Thanks to its robust IP67 certified housing, it is resistant to water, dust, and vibrations, ensuring maximum reliability even in difficult conditions. Compact and efficient, it offers a stable 12 V output voltage for a wide range of devices.
Key Features
-
Wide input range: accepts voltages from 15 to 80 V, compatible with most 24 V, 36 V, 48 V, 60 V, and 72 V systems.
-
Stable Output: Efficiently converts to 12 V / 3 A (36 W) to power lights, GPS, USB ports, or other accessories.
-
Comprehensive Protection: Against overvoltage, overcurrent, short circuits, and overheating.
-
IP67 Waterproof Rating: Sealed aluminum casing, resistant to water and dust.
-
Easy Installation: Pre-wired connection cables for quick assembly.
Technical Description
| Specification |
Detail |
| Product Type |
DC-DC Converter |
| Input Voltage |
15–80 V DC |
| Output Voltage |
12 V DC |
| Output Current |
3 A |
| Maximum Power |
36 W |
| Efficiency |
> 95 % |
| Protection |
Overvoltage, overcurrent, short circuit, overheating |
| Protection Rating |
IP67 (waterproof and dustproof) |
| Case Material |
Anodized aluminum |
| Cooling |
Passive (fanless) |
| Operating temperature |
-20 °C to +60 °C |
| Dimensions |
Approximately 74 × 74 × 32 mm |
| Weight |
Approximately 150 g |
| Applications |
Electric bike, scooter, kick scooter, 12 V vehicle |
